Title: Personnel information system using sorting and searching for STL and vector
container.
Problem
Statement:
Write C++ program using STL for sorting and searching user defined records such as
personal records (Name, DOB, Telephone number etc) using vector container. OR
Write C++ program using STL for sorting and searching user defined records such as
Item records (Item code, name, cost, quantity etc) using vector container.
Prerequisites:
Object Oriented Programming
Objectives:
To learn the concept STL, searching, sorting and vector container.
Theory:
STL:
The Standard Template Library (STL) is a set of C++ template classes to provide common programming
data structures and functions such as lists, stacks, arrays, etc. It is a library of container classes,
algorithms, and iterators. It is a generalized library and so, its components are parameterized.
A working knowledge of template classes is a prerequisite for working with STL.
STL has four components
Algorithms
Containers
Functions
Iterators
Algorithms
The algorithm defines a collection of functions especially designed to be used on ranges of
elements.They act on containers and provide means for various operations for the contents of
the containers.
Algorithm
Sorting
Searching
Important STL Algorithms
Useful Array algorithms
Partition Operations
Numeric
Containers
Containers or container classes store objects and data. There are in total seven standard “firstclass” container classes and three container adaptor classes and only seven header files that
provide access to these containers or container adaptors.
Sequence Containers: implement data structures which can be accessed in a sequential
manner.
vector
list
deque
arrays
forward_list ( Introduced in C++11)
Container Adaptors : provide a different interface for sequential containers.
queue
priority_queue
stack
Associative Containers : implement sorted data structures that can be
quickly searched (O(logn) complexity).
set
multiset
map
multimap
Unordered Associative Containers : implement unordered data structures that can be quickly
searched
unordered_set
unordered_multiset
unordered_map
unordered_multimap
Functions
The STL includes classes that overload the function call operator. Instances of
such classes are called function objects or functors. Functors allow the working
of the associated function to be customized with the help of parameters to be
passed.
Iterators
As the name suggests, iterators are used for working upon a sequence
of values. They are themajor feature that allow generality in STL.
Utility Library
Defined in header <utility>.
pair
Sorting:
It is one of the most basic functions applied to data. It means arranging the data in
a particular fashion,which can be increasing or decreasing. There is a builtin
function in C++ STL by the name of sort(). This function internally uses IntroSort.
In more details it is implemented using hybrid of QuickSort,
HeapSort and InsertionSort.By default, it uses QuickSort but if QuickSort is
doing unfair partitioning and taking more than N*logN time, it switches to
HeapSort and when the array size becomes really
small, it switches to
InsertionSort. The prototype for sort is :
sort(startaddress, endaddress)
startaddress: the address of the first element of the array
endaddress: the address of the next contiguous location of the last element of the
array.So actually sort() sorts in the range of [startaddress,endaddress)
//Sorting
#include <algorithm>
#include <iostream>
Using namespace std;
voidshow(inta[], intarraysize)
{
for(inti = 0; i <arraysize; ++i) cout<< a[i] << " ";
}
Int main()
{
inta[] = { 1, 5, 8, 9, 6, 7, 3, 4, 2, 0 };
intasize = sizeof(a) / sizeof(a[0]); cout<< "\n The array is : "; show(a, asize);
cout<< "\n\nLet's say we want to search for 2 in the array"; cout<< "\n So, we first sort the array";
sort(a, a + asize);
cout<< "\n\n The array after sorting is : "; show(a, asize);
cout<< "\n\nNow, we do the binary search"; if(binary_search(a, a + 10, 2))
cout<< "\nElement found in the array"; else
cout<< "\nElement not found in the array";
cout<< "\n\nNow, say we want to search for 10"; if(binary_search(a, a + 10, 10))
cout<< "\nElement found in the array"; else
cout<< "\nElement not found in the array";
return0;
}
Output:
The array is : 1 5 8 9 0 6 7 3 4 2 0
Let's say we want to search for 2 in the array
So, we first sort the array
The array after sorting is :
0 1 2 3 4 5 6 7 8 9
Now, we do the binary search
Element found in the array
Now, say we want to search for 10 Element not found in the array
Facilities:
Linux Operating Systems, G++
Algorithm:
1. Start.
2. Give a header file to use ‘vector’.
3. Create a vector naming ‘personal_records’.
4. Initialize variables to store name, birth date and telephone number.
5. Using iterator store as many records you want to store using predefined
functions aspush_back().
6. Create another vector ‘item_record’
7. Initialize variables to store item code, item name, quantity and cost.
8. Using iterator and predefined functions store the data.
9. Using predefined function sort(), sort the data stored according to user requirements.
10. Using predefined function search, search the element from the vector the user wants to
check.
11. Display and call the functions using a menu.
End.
Input:
Personnel information such as name, DOB, telephone number.
Output:
Display personnel information from database. The result in following format:
***** Menu *****
1.Insert
2.Display
3.Search
4.Sort
5.Delete
6.Exit
Enter your choice:1
Enter Item Name: bat
Enter Item Quantity:2
Enter Item Cost:50
Enter Item Code:1
Conclusion:
Hence, we have successfully studied the concept of STL(Standard Template Library) and how it
makes many data structures easy. It briefs about the predefined functions of STL and their uses such
asearch() and sort()
Questions :
1. What is STL? What are four components of STL?
2. What is Sorting & Searching?
3. What vector container?
